Our General diesel water pump sets:
Usage: Farm irrigation,fire fighting,industrial watering,mining etc.
Treated Water: Fresh water,River water
Outflow range:15-8000m³/h
Head Lift range:5-10000m
=================================================================

Specific Case characterization :

Diesel engine parameters:
1)Model:R6105ZD
2)Rated output(KW):75KW
3)Rated speed(r/min):1500
4)Starting method: Electric motor 24V DC
5)Cooling method: Air cooling
6)Governing method: Mechanical/Electronic governing(Optional)
7)Intake method: Turbocharged intercooled
8)Cylinders:6
9)Bore/Stroke:105/125mm
10)Type: in line,4 stroke, humid liner, direct injection

Water pump parameters:
1)Model:IS200-150-400
2)Type: Single stage, single suction, centrifugal
3)Outflow:300m3/h
4)Head:51m
5)Shaft power:67.2KW
6)Inlet diameter:200mm
7)Outlet diameter:150mm
8)Impeller diameter: 400mm
9)Casing material: cast iron
10)Shaft material: cast iron
11)Impeller material:cast iron
12)Sealing method: Stuffing sealing/Mechanical sealing(Optional)

Control system(OPTIONAL):
1)AMF/ATS function
2)Warning of oil low pressure, slow speed, high water temperature, high oil temperature etc
3)Display functions with warning ,Auto start and stop
4)Weather canopy,trailer type,movalbe type,silent case

Quality Gurantee:1year/1000working hours(the first reach is valid )
